Specialized S-Works Crux

Specialized S-Works Crux
Color: Gloss Birch Red Gold Pearl Speckle/Red Gold
Size: Select size
Wheel Size: 700c
Please select options Unavailable
Order now and pick up in-store for free


The Crux is the lightest gravel bike in the world, with the exceptional capability of massive tire clearance and performance gravel geometry. It's not just the ultimate expression of gravel performance, it's your one-way ticket to gravel enlightenment.

This S-Works Crux comes spec'd with SRAM's pinnacle RED eTap AXS hydraulic disc groupset, lightweight and durable Roval Terra CLX Disc wheels, and 2Bliss Ready, 700x38mm Pathfinder Pro tires that hookup over nasty terrain.

- Lightest: 725g S-Works 12r and 825g 10r frames. We took the revolutionary breakthroughs that made Aethos the lightest bike ever and applied them to the Crux. The result? A gravel bike that climbs like a dream, floats over nightmarish terrain, and weighs less than a full bottle in your cage.

- Capable: 47c/650b x 2.1" tire clearance. More clearance means more capability. With Diverge-level tire clearance, Crux takes you anywhere you can imagine, at full gas.

- Responsive: Nimble, supple, and reactive. Responsive at the pedals. Supple in the saddle. With performance gravel geometry and race-influenced fit inspired by Crux's iconic history in 'cross.

Size (cm)495254565861
Crank Length (mm)165 170172.5172.5175175
Handlebar Width (mm)380 400420420440440
Stem Length (mm)70 8090100110110
Saddle Width (mm)155 155143143143143
Seatpost Length (mm)300 300300360360360
Wheelbase (mm)1008 10141023103310451059
Chainstay Length (mm)425 425425425425425
Head Tube Length (mm)100 115130147167190
Head Tube Angle (°)70.5 71.2571.57272.2572.5
BB Height (mm)284 284286286286286
Fork Rake/Offset (mm)50 5050505050
Seat Tube Length (mm)466 496521546576606
Stack (mm)530 547560578598621
Fork Length, Full (mm)401 401401401401401
Front Center (mm)594 600608618630644
Reach (mm)375 382388397405415
Seat Tube Angle (°)75.5 747473.573.573.5
BB Drop (mm)74 7472727272
Trail (mm)74 6967646260
Top Tube Length, Horizontal (mm)512 539549568582599
Bike Standover Height (mm)749 772794816841866
5'1"- 5'4" 155-158 49
5'4"-5'6" 163-168 52
5'6"-5'9" 168-175 54
5'9"-6'0" 175-183 56
6'0"-6'3" 183-191 58


Pedals Sold Separately
Fork S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc
Stem S-Works SL, alloy, titanium bolts, 6-degree rise
Chain SRAM CN RED D1 12S 114LI
Frame S-Works Crux FACT 12r Carbon, Rider First Engineered™, Threaded BB, 12x142mm thru-axle, flat-mount disc
Tires Pathfinder Pro, 2Bliss Ready, transparent sidewall, 700x38mm
Saddle Body Geometry S-Works Power, carbon fiber rails, carbon fiber base
Crankset SRAM Red AXS, 40T
Seatpost Roval Alpinist Carbon Seatpost
Shifters SRAM Red eTap AXS
Chainrings Steel, 30T
Handlebars Roval Terra, carbon, 103mm drop x 70mm reach x 12º flare
Tape/Grips Supacaz Super Sticky Kush
Bottom Bracket SRAM DUB BSA 68
Rear Derailleur SRAM Red XPLR eTap AXS
Cassette/Freewheel SRAM XPLR, XG-1271, 12-speed, 10-44t

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Gloss Birch Red Gold Pearl Speckle/Red Gold / 52cm / 700c 888818858583 91423-0052 CRU214780902
Gloss Birch Red Gold Pearl Speckle/Red Gold / 54cm / 700c 888818858699 91423-0054 CRU217346974
